L 120 Pendant Lamp

Measurements: L.880, 1160, 1440, 1720 , 2000 x H.canopy 35 x W.430 x D.110 mm



Wood: W.40 x H.120 mm



Weight: 3,5, 5,0, 6,5, 8,6 Kg



Suspension Height: 2 m - The cable can be shortened



Power Cable Length: 3 m - The cable can be shortened



Mounting and Connection: Canopy and connection in the same position

Light Direction: Direct / Indirect



Adjustability: Fixed



Light Source: LED



LED Lifespan: 50,000 hours



Power: 36, 48, 62, 72 Watt



Voltage: 180 - 295 V



Lumen: 1500, 2200, 3260, 3600 lm



Color Temperature: 2700 K (warm white), 3000 K (soft white)



Color Rendering: Ra = 93 (best possible color rendering Ra = 100)



Unified Glare Rating:

• Microprism Optics: UGR<19 (Low glare)

• Honeycomb Optics: UGR<16 (Ultra-low glare)

Control Via: DALI system

4-Wire System: Requires active, neutral, and two control wires at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Wall switch (DALI)



Control Via: Push system

3-Wire System: Requires active, neutral, and one control wire at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Wall switch (Push)



Control Via: Casambi Bluetooth system

2-wire system: Requires active and neutral wires at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Tunto EnOcean switch/ Smartphone/ Tablet

* Choose the double rocker to control/ dim the up and down lights individually

Installation: All installation work must be carried out by qualified personnel



Safety Class: IP20 - Protected against solid foreign matter with a diameter starting at 12.5 mm, no water protection



Protection Class: Class II



Marking: CE mark



Use: Indoor use only



Exchange LED Module: Non-user replaceable light source

Wood Quality: Wood, being a vibrant and organic material, exhibits natural variations in patterns and shades. Additionally, its hue may evolve over time as the material matures.



Cleaning: We recommend dusting your model frequently with a clean, soft, dry, lint-free cloth



Care: Avoid extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units

Product Information: Download

Assembly Instruction: Download



Casambi Driver (LCM40BLE): Download

Dali/ Push Driver (LCM40DA): Download

Round Canopy: 2Lines

Recommended Model: Choose ⌀ 280 mm



Wireless Switch: Tunto EnOcean Switch

Recommended Model: Double rocker

Required Driver: Casambi Dim
