Cube Wall & Ceiling Lamp

Measurements - S: H.165 x W.220 x D.125 mm / 0,9 Kg

Measurements - M: H.220 x W.250 x D.125 mm / 1,2 Kg

Measurements - L: H.250 x W.280 x D.85 mm / 1,8 Kg

Measurements - XL: H.280 x W.500 x D.85 mm / 3 Kg

Measurements - XXL: H.500 x W.500 x D.125 mm / 4,5 Kg



Wood Thickness: 4 mm



Mounting and Connection: Wall mounting and connection in the same position

Light Direction: Light directed in all directions



Adjustability: Fixed



Light Source: LED



Power: S.11, M.16, L.20, XL.28, XXL,37 Watt



Voltage: 180 - 277 V



Lumen: S.440, M.830, L.1000, XL.1300, XXL.1800 lm



Color Temperature: 2700, 3000 Kelvin



Color Tendering: Ra = 93 (best possible color rendering Ra = 100)

Control Via: DALI system

4-Wire System: Requires active, neutral, and two control wires at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Wall switch (DALI)



Control Via: Push system

3-Wire System: Requires active, neutral, and one control wire at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Wall switch (Push)



Control Via: Casambi Bluetooth system

2-Wire System: Requires active and neutral wires at the ceiling outlet

Dimming: Continuously dimmable

External Operation: Tunto EnOcean switch/ smartphone/ tablet

Installation: All installation work must be carried out by qualified personnel



Safety Class: IP20 - Protected against solid foreign matter with a diameter starting at 12.5 mm, no water protection



Protection Class: Class III



Marking: CE mark



Use: Indoor use only



Exchange LED Module: Non-user replaceable light source

Wood Quality: Wood, being a vibrant and organic material, exhibits natural variations in patterns and shades. Additionally, its hue may evolve over time as the material matures.



Cleaning: We recommend dusting your model frequently with a clean, soft, dry, lint-free cloth



Care: Avoid extreme changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units

Product Information: Download

Assembly Instruction: Download



Casambi Driver (LCM25BLE): Download

Casambi Driver (LCM40BLE): Download

Dali/ Push Driver (LCM25DA): Download

Dali/ Push Driver (LCM40DA): Download

Cube Small: 2700 Kelvin, 3000 Kelvin

Cube Medium: 2700 Kelvin, 3000 Kelvin

Cube Large: 2700 Kelvin, 3000 Kelvin

Cube XL: 2700 Kelvin, 3000 Kelvin

Cube XXL: 2700 Kelvin, 3000 Kelvin

Wireless Switch: Tunto EnOcean Switch

Recommended Model: Single rocker

Required Driver: Casambi Dim
